5 Link Kit
KHC 5 Link rear suspension kit is a result of countless hours of cad design using a parallel 4 link concept with panhard bar.Capable of 17-19in of travel using 16 travel coilovers and 18 travel bypass shocks. Upper links are made from 7075 Aluminum.All frame brackets are bolt on with the only welding required being the axle brackets.Modular Bedcage is capable of holding 2 tires standing with equipment in the middle or one single tire laying down allowing a bed cover to be used. Kit includes KHC trailing arms with rock guards along with our rear sway bar kit designed specifically for our rear suspension kits giving the truck a very stable feel on the street and offroad.Integrated bump stop system uses 2.5 bump stops.
Parts included:
- Trailing arms
- Upper links
- Panhard bar
- Frame mounts for trailing arms and upper links
- Bed Cage with all frame mounts
- Rear sway bar kit with frame mounts
- Axle brackets/strike plates and truss (weld on) Currie or stock axle
- 1 ¼ TMR hiems/FK hiems
- Straps and mounting hardware
Note:
- Exhaust modification required
- Removal of all factory spring mount brackets and shock mounts required
- 16 travel 3.0 coilovers/18 travel bypass shocks and 2.5 bump stops
- Custom brake lines required
- Axle housing mount welding required
