Description
Adapt: While everybody loves RGB Gear, not everybody is always on the same standard. Some manufactures use "RGB" pin connectors, and others use "JST" connectors. These adapters will help you get you gear working together! Options: These are available in a variety of different combinations. Please make sure to double check your setup and order the correct ones. Note that when referring to male/female - we are referring to the pins inside the connectors... NOT the plastic housing. Standard: All adapters are wired according to the industry-standard GRGB order. While they should work with most accessories out there, we cannot guarantee it. Plug n Play: With these convenient adapters, there should be no need to cut/splice/re-pin any of the small wiring associated with your RGB products. They are designed to be plug n play with various RGB accessories, and virtually everything sold by LEDC.
Tech Specs
WIRE THICKNESS: 14 AWG
LENGTH: Approx. 6in / 150mm
INSULATION: Braided TechFlex
Connector 1: JST Female
Connector 2: JST Female 4P
Intensity: 78,000 Cd (@20 Min. / 21C Ambient) (780lux @ 10m)
Input: Proprietary Overmolded Deutsch DT 2-Pin w/ Pigtail
Input Voltage: 9-18V DC
Power: 42w
Current: 3.2A @ 13.2V DC
Dimensions: 82mm W, 67mm H, 60mm D
Color: 5700K
Light Source: 3x Osram HX Boost (5700K)
Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
IP Rating: IP68K (Dust / High Pressure Water Resistant)
What's Included
Wiring Adapter: 1x JST Female to JST Female Adapter
Warranty: 2 Years
Compatibilities
INPUT TYPE: JST 4-Pin Female
OUTPUT TYPE: JST 4-Pin Female
Prop65 Warning
Yes
DOT Compliant
Yes
Install Guide
Download Install Guide
